Product highlights:
4-channel car amplifier
60 watts RMS x 4 at 4 ohms
90 watts RMS x 4 at 2 ohms
180 watts RMS x 2 bridged at 4 ohms
Hi-Res Audio Certified (frequency response: 20-40k Hz)
variable high- and low-pass filters (50-400 Hz, 12 dB/octave)
variable mid-bass boost (0-12 dB at 100 Hz) on Ch 3/4
optional wired remote available for Ch 3/4
More info:
preamp and speaker-level inputs
speaker-level inputs handle up to 10V
RCA adapters required for speaker-level input
signal-sensing turn-on with speaker-level inputs
wiring and hardware not included with amplifier
8-gauge power and ground leads recommended
fuse rating: 40A x 1
dimensions: 8.66"W x 2.21"H x 8.3"D
