7" WVGA (800 x 480) TFT-LCD with Capacitive Anti-Glare Glass-Touchscreen
7 Display Colors Customization for LED Key Light
Display Off Mode & Dimmer Setting
Apple CarPlay with Wired USB connection
Voice Command for iPhone Siri (Only CarPlay)
iPhone Airplay with Wired USB connection
Full-HD Video(MPEG-4, H.264, DivX, Xvid Codec) Playback from USB Devices
Audio(MP3, WMA, AAC, WAV, FLAC, OGG Codec) Playback from USB Devices
ID3 MP3 Tag Reading For Track & Artist Information
Bluetooth V4.2 Hands Free Profile (HFP) Calling from Enabled Devices
A2DP Wireless MP3 Audio Playback from Enabled Devices
Bluetooth Phonebook and Time Alignment (only iPhone)
RDS-FM/AM Receiver with 18FM, 12AM Presets
Best Station Memory (BSM), Preset Scan (PS) Function, Local Seek Tuning
Time Alignment (CT), Alternative Frequency (AF), Programme Type (PTY), TA for RDS
Front, Rear & Subwoofer Audio 6-RCA 2V Preouts
Built-in MOSFET 55W x 4Ch. Amplifier (at 4ohm)
16-Band Graphic Custom & Preset Equalizer Settings
Selectable Front USB Port or Rear USB Port for Smartphone Link
Front Panel USB Port & Rear 5ft (1.5m) USB Extension Cable
AUX/Video Input for Personal Media Devices
CVBS Video Output for Auxiliary Devices
Front Camera Input (Automatic switching to front camera view after reverse)
Rear View Camera Input with Trigger when Backing Up
Support High Definition Camera Connection for Front View & Rear View
Built-in Front Panel Microphone for Bluetooth Hands-Free
Rear Expansion 18ft(5m) Wired Microphone for High Quality of Voice
Steering Wheel Control Interface
Illumination Signal Input for LCD Dimmer
Line Out for Power Amp Remote Control (10 seconds after turned off)
Line Out for Auto Antenna (10 seconds after turned off)
Automatic Front Camera Power Control after Reverse
Parking Brake Detection for Safe Driving and Unlawful Use while Driving
IR Remote Control Ready (Remote is Optional)
1.5A High Current USB Charging for Smartphone
Multi-Language Display (English, español, français, português, Deutsch, italiano, русский, Türkçe العربية، فارسی Bahasa Indonesia, 中文, 한국어 (or 日本語(
World's First Actual ISO 2-DIN Size Design with 7" Full Size Display
Nose Dimensions (W x H x D): 6-3/4" x 3-7/8" x 1/8" (171 x 97 x 2 mm)
Chassis Dimensions (W x H x D): 7" x 3-15/16" x 6" (178 x 100 x 153 mm)
